Platform
OS: Linux
SoC: Qualcomm® QRB5165N
Storage
Flash: 128GB UFS3.0
Expansion: 1 x Micro SD Card slot, M.2 Con for 2280 SSD NVMe
Peripheral Interface
HDMI: 1 x HDMI out, 1080p@60fps; 1 x HDMI in, 4k@60fps
Audio in/out: 1 x MIC, 1 x Earphone
Ethernet: 2 x RJ45, Gigabit ethernet(10/100M/1000M)
USB: 3 x USB 3.0 Type-A, 1 x USB3.1 Type-C (support Video and OTG)
COM Port: 2 x RS485, 2 x RS232 default (2 x CAN optional with RS232)
DI/DO: 4 x DI(Photocoupler), 2 x DO (Switch: Short/OFF)
SIM: 1x Nano SIM card slot
Antenna: 6 x Antenna interfaces for 4G/5G, Wi-Fi and GPS function
Debug Port: 1 x Micro USB(for debug), 1 x Micro USB(for 4G/5G module)
Wireless Connectivity
4G/5G:
- M.2 CON for 3042 4G / 3052 5G module, spport PCIe and USB data bus
- 5G module support: 2G/3G/4G/5G NR sub-6
WiFi: M.2 CON, support M.2 Wi-Fi module
GPS: GPS, Beidou and others
Power
DC Input: Input DC range support from 12V to 24V
Buttons & Indicators
Buttons: Power key, Reset key
LEDs: Power status, 5G Status
Audio: 1 x Buzzer
Others
RTC Battery: CR2032 RTC Battery
Mechanical
Dimension: 235mm x 200mm x 42mm
Mount: Desktop, Wall mount
Environment
Operation Temperature: -20℃ ~ +60℃
Storage Temperature: -40℃ ~ +70℃
Storage Humidity: 5%~95%, non-condensing
Waterproof: IP40
