Thundercomm - TurboX EB5-R5 Edge AI Station
£1,129.06 - £1,319.49
EB5 Edge AI Station is a high-performance AI edge computing device with support for 5G and Wi-Fi 6. It adopts an industrial-grade fanless design and is deeply optimized at the operating system level to maximize product performance. Embedded with the built-in edge component OSware.Edge, it provides customers with device management, video management, AI algorithm configuration, application upgrades, edge-cloud collaboration, customization, and multi-cloud connectivity.
EB5 delivers superior 15 TOPS of AI performance and up to 24 channels full HD video processing, which can be widely used in smart retail, smart buildings, smart factories, smart transportation, and many other edge AI application scenarios.
Note: This is the Linux version. For an Android version, please click here.
Optional components
Choose Quantity
Product Details
- Industrial-grade hardware: Industrial grade with fanless design, can be used in a wide operating temperature from -10℃ to ~60℃.
- Flexible cloud connectivity: Can leverage both public cloud like AWS, Microsoft Azure and private cloud, with the modular design of the middleware can be configured per specific scenarios.
- Powerful chipset: Support 24 channels FHD video decode, with 15TOPS @INT8 AI performance.
- Simplified usage: Compact design and low power consumption, support remote deployment, upgrade and device management.
- Intelligent ware: Provide built-in TurboX Edge OS, including device-edge-cloud synergy ware TurboX Device and TurboX Cloud, multimedia processing and AI analysis ware TurboX Stream
EB5 Edge AI Station Features
Premium performance with super high AI computing power
For intelligent edge computing, EB5 provides 15 TOPS super high AI computing power and supports up to 24 channels of 1080P HD video decoding, which is suitable for multi-channel video streaming AI analysis scenarios such as buildings, communities, schools, factories, and retail.
Deeply optimized streaming media AI analysis service
With built-in deeply optimized streaming media AI analysis service TurboX Stream, EB5 features image zero copy, hardware acceleration, batch reasoning, algorithm sharing, and supports standard libraries such as SPL, ALG, AND MBC, making AI algorithm deployment, verification, and delivery easy and fast.
Visual configuration of AI algorithms and applications
EB5 provides a visual edge management system for device management, video previewing, algorithm configuration, alarm center, and application upgrade. It also provides RESTful APIs and supports interconnection with third-party systems.
One-site management through End-edge-cloud
With the intelligent edge device and application management platform IoT Harbor, the remote monitoring and analysis of multiple EB5 operating status and resource usage can be realized to facilitate user operation and management. IoT Harbor provides RESTful APIs to support multi-cloud connection.
Industrial design for harsh conditions
Robust industrial level quality, fanless design, ultra-low power consumption, flexible deployment, plug and play, safe and reliable, easy to cope with any complex environment challenges.
Flexible expansion of rich interfaces
EB5 supports 5G, Wi-Fi 6, adaptive Gigabit Ethernet connections, RS232, RS485, CAN, USB3.0 and other industrial communication interfaces. It also supports SD cards, M.2 SSD expansion, covering different intelligent edge application scenarios.
EB5 Edge AI Station Applications
- Smart Retail
- Smart Building
- Smart Factory
- Smart Transportation
- Smart Grid
EB5-R5 Edge AI Station Specifications
Platform
OS: Linux
SoC: Qualcomm® QRB5165
Qualcomm® Artificial Intelligence (AI) Engine 15 TOPS:
- CPU: Qualcomm® Kryo™ 585 CPU, CPU Clock Speed: Up to 2.84 GHz
- GPU: Qualcomm® Adreno™ 650 GPU
- DSP: Qualcomm® Hexagon™ 698 Processor
Image Processor: Qualcomm® Spectra™ 480 image processing
Video Processor: Qualcomm® Adreno™ 665 VPU, H264 & H265 codec support; video decoding: 8k@60fps; video encoding: 8k@30fps
Display
Output: 2x HDMI out, 1080p@60fps
Storage
Flash: 128GB UFS3.0 on board
Expansion: 1x Micro SD Card slot, support M.2 2280 NVME SSD (SSD optional)
Peripheral I/O
USB: 4 x USB 3.0 Type A , 1 x USB3.1 Type C(OTG)
Micro SD: 1x Micro SD slot
SIM: 1x Nano SIM card slot
Ethernet: 2 x Gigabit ethernet(10/100M/1000M)
COM Port: 2 x RS485, 2 x RS232
CAN: 2x CAN bus
DI/DO: 8 DI/DO(4 DI, 4 DO)
Wireless Connectivity
Wi-Fi: 802.11a/b/g/n/ac/ax, 2x2 MIMO
5G: M.2 5G module(optional), multimode support: 2G/3G/4G//5G NR sub-6
Antenna: 6x Antenna connector(2x for WIFI,4x for 5G)
Audio
Audio: 1 x MIC, 1 x Earphone
Debug
Debug Port: 1x Micro USB( for debug)
Power
DC Input: DC 12V to 24V
Input & Indicators
Buttons: Power key, Reset key
LEDs: Power status, WiFi status, 5G Status
Others
RTC Battery: CR2032 RTC Battery
Certification
CE NB, FCC, JATE/TELEC, RoHS/Reach/WEEE
