SparkLAN WPEB-265AXI(BT) [B33] Industrial Grade Half Mini PCIe Module

WPEB-265AXI(BT) series is a WLAN 802.11ax (WiFi 6) Combo Module, 802.11ax (WiFi 6) allow efficient allocation of low data-rate connections, improve the battery life of IoT sensors, and extend the range of Wi-Fi signals. The new 802.11ax standard with its unique features such as OFDMA, 1024QAM, Target Wake Time (TWT). WPEB-265AXI(BT) series enables smooth streaming of high-resolution videos, fewer dropped connections and faster connections farther away from the router and in dense environments.

There are two basic types of WPEB-265AXI(BT) Series models, one is USB interface for BT the other is UART interface for BT. The Operating Voltage support DC 3.3V. The 802.11ax (WiFi 6) half mini PCIe module can support Multi-User MIMO (MU-MIMO) technology to increase channel capacity when simultaneously servicing multiple devices using the same frequency chunks. BT 5 provides doubles data rates speed for faster transmissions thereby reducing the overall power consumption. Additionally, BT 5 adds new enhanced data broadcasting enabling seamless services.

WPEB-265AXI(BT) module can support the Soft AP mode and Station (Client) mode. the product can be connected to a wireless network as a Client, while also creating a separate network as an AP for other devices to connect to it.
