RUTXR1 Enterprise Rack-Mountable SFP/LTE Router

RUTXR1 Enterprise Rack-Mountable SFP/LTE Router

RUTXR1, the first rack-mountable LTE Cat 6 router in the Teltonika Networks portfolio, comes with redundant power supplies, WAN failover, dual-SIM, SFP, USB, and dedicated console ports.

This feature-rich device with highly customizable and powerful RutOS is perfect where a fast and ultra-reliable connection is needed.

4G LTE CAT 6 - Cellular speeds up to 300Mbps with Carrier Aggregation
SFP - SFP port for long-range Fiber-optic communication
WI-FI - Wave-2 802.11ac Dual Band WI-FI
DUAL POWER - Dual Power supply compatibility ensures uninterrupted service

Looking to connect your device? Try our free Wireless Logic SIM with 2 week trial now!
Click here to view and add to your basket for free >>

£325.49

Additional information

Data Sheet/Product Brief

https://bcdatlantik.co.uk//bcd-assets/specsheets/rutxr1-datasheet-v16.pdf

Expected delivery time

10-14 working days

Product Details

Key features of RUTXR1

Hardware

Mobile: 4G (LTE) – Cat 6 DL up to 300 Mbps, UL up to 50Mbps; DC-HSDPA; HSUPA; WCDMA
CPU: Quad Core ARM Cortex A7 717 MHz CPU
Memory: 256 MB SPI Flash, 256 MB of DDR3 RAM
Ethernet: 4 x LAN ports 10/100/1000 Mbps, 1 x WAN port (can be used as LAN) 10/100/1000 Mbps
SFP: 1 x SFP port for Optical interface
WiFi: 802.11ac (WiFi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)
Power supply: Dual 9 - 50 VDC, 4 pin DC connectors
Connectors: 2 x 4 pin DC, 5 x Ethernet, 1 x SFP, 2 x SMA for LTE, 2 x RP-SMA for WiFi, 1 x RJ45 console, 1 x USB, Grounding terminal
SIM: 2 x external SIM holders
Status LEDs: 2 x Power, 2 x SIM status, 2 x Mobile connection type, 3 x Mobile connection signal strength LEDs, 2 x WAN connection type, 4 x Ethernet status
Operating temperature: -40 °C to 75 °C
Housing: Full aluminium Rack Unit housing, 1U height
Dimensions: 272 mm x 123 mm x 43.66 mm

Software

Operating system: RutOS (OpenWrt based Linux OS)
SIM switch: 2 SIM cards, auto-switch cases: data limit, no network, network denied, data connection fail
Multiple PDN: Possibility to use different PDNs for multiple network access and services
Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DHCP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, Telnet
Networking features: NAT, Static/Dynamic routing, Firewall, OpenVPN, IPSec, H.232 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Unique networking features: VLAN, Mobile quota control, WEB Filter, Load Balancing, Network Backup, Auto Failover
Connection monitoring: Ping Reboot, Periodic Reboot, LCP and ICMP for link inspection
Authetication: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block
Keep settings: Update FW without losing current configuration
Connection monitoring: WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS
Authetication: Busybox shell, Lua, C, C++
Keep settings: SDK package with build environment provided
