RUTX10 Professional Ethernet Router

The RUTX10 professional router from Teltonika Networks combines the best of wired and wireless routing functionalities with Gigabit Ethernet, Bluetooth LE, and AC Wi-Fi.

Advanced remote management capabilities, along with numerous supported security and networking protocols, make the RUTX10 an ideal choice for professional applications.

GIGABIT ETH - 4 x Gigabit Ethernet ports with up to 128 port/tag-based VLANs supported
WI-FI & BT - Wave-2 802.11ac Dual Band WI-FI and Bluetooth LE
VPN - Numerous VPN Protocols supported, including OpenVPN, IPsec, PPTP, L2TP & DMVPN
RMS - Compatible with Teltonika Networks Remote Management System

Looking to connect your device? Try our free Wireless Logic SIM with 2 week trial now!
Click here to view and add to your basket for free >>

£175.95

Additional information

Data Sheet/Product Brief

https://bcdatlantik.co.uk//bcd-assets/specsheets/rutx10-datasheet-v10.pdf

Expected delivery time

Not all of our products are held in our local warehouse. After placing an order we will contact you with a proposed delivery date. If you would like to know the status before placing an order, please contact us.

Available Offer

Product Details

The RUTX10 Enterprise router has been designed specially for small to mid-size office applications.

It comes with Dual Band Wi-Fi 5 802.11ac, which is very suitable for high data transmission and robust wireless performance.

It has all the latest security features and allows remote monitoring and control.

RUTX10 comes with highly functional & customizable RutOS based on OpenWRT.

Synergy between hardware and software makes this device an amazing performer in Enterprise solutions.

Key features of RUTX10

Hardware

CPU: Qualcomm, 4 x ARM Cortex A7, 717 MHz
Storage: 256 MB Flash
Memory: 256 MB RAM
Powering option: 4pin power socket, 9-50 VDC
Antenna connectors: 2 x RP-SMA for WiFi, 1 x RP-SMA for Bluetooth
Ethernet: 4 x 10/100/1000 Ethernet ports: 1 x WAN (configurable as LAN), 3 x LAN
WiFi: IEEE 802.11b/g/n 2.4GHz, IEEE 802.11ac/n/a 5GHz, Access point (AP), Station (STA)
Bluetooth: 4.0 (Low energy)
Inputs/Outputs: On 4pin socket: 1 x Digital input, 1 x Digital open collector output
Other: 1 x USB Host
Status LEDs: 2 x WiFi, 8 x Ethernet, 1 x Power
Operating temperature: -40 °C to 75 °C
Housing: Aluminium housing with DIN rail mounting option and grounding capability
Dimensions (W x H x D): 115 x 32.2 x 95.2 mm
Weight: 355g

Software

Operating system: RutOS (OpenWrt based Linux OS)
Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPoE, DHCP, Telnet
Routing: Static routes, Dynamic routes (BGP, OSPFv2, RIPv1/v2, EIGRP, NHRP), Routing rules
VPN and tunneling: OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, WireGuard, ZeroTier
Monitoring and Management: WEB UI, CLI, SSH, TR-069, SNMP, JSON-RPC, MQTT, MODBUS, RMS
Connection monitoring: Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
Cloud solutions: RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
Hotspot: External/Internal Radius, SMS OTP, MAC authentication, Walled Garden
Supported Hotspot platforms: IronWiFi, HotspotSystem, Cloud4Wi, SAI + WiFi, MugiCloud, Purple.ai
Services: DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Network shares (Samba), Traffic Logging
