RUT906 4G LTE RS232/RS485 Router
£204.43
Cellular 4G router for industrial IoT applications, supporting serial interfaces RS232 and RS485, MQTT, BACnet, I/Os, Ethernet, and more.
The RUT906 cellular router from Teltonika Networks is equipped with GNSS and failsafe features such as Dual SIM, auto-failover, and backup WAN.
- CONNECTIVITY - 4G/LTE (Cat 4), 3G, 2G
- DUAL SIM - With auto failover, backup WAN and other switching scenarios
- INTERFACES & PROTOCOLS - Serial interfaces (RS232 & RS485), MQTT, BACnet, OPC UA, I/Os, Ethernet, and more
- GNSS - NTRIP, location services and time synchronization
Data Sheet/Product Brief
https://bcdatlantik.co.uk//bcd-assets/specsheets/rut906-datasheet-2023-v11.pdf Expected delivery time
10-14 working days Choose Quantity
Product Details
Cellular 4G router for industrial IoT applications, supporting serial interfaces RS232 and RS485, MQTT, BACnet, I/Os, Ethernet, and more. This cellular router is equipped with GNSS and failsafe features such as Dual SIM, auto-failover, and backup WAN.
Key features of RUT906
Hardware
- Mobile: 4G (LTE) - Cat 4 up to 150 Mbps, 3G - up to 42 Mbps, 2G - up to 236.8 kbps
- CPU: Mediatek, MIPS 24Kc, 580 MHz
- Storage: 16 MB, SPI Flash
- Memory: 128 MB, DDR2
- Powering option: 4-pin industrial DC power socket, 9-30 VDC
- SIM: 2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders, eSIM (Optional)
- Antenna connectors: 2 x SMA for LTE, 2 x RP-SMA for WiFi, 1 x SMA for GNSS
- Ethernet: 4 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 3 x LAN
- WiFi: IEEE 802.11b/g/n, Access point (AP), Station (STA)
- Inputs/Outputs: 2 x Inputs and 2 x Outputs on 10-pin industrial socket, 1 x Digital input and 1 x Digital output on 4-pin power connector
- Serial: 1 x RS232, 1 x RS485
- Other: 1 x USB host
- Status LEDs: 1 x bi-color connection status, 5 x Mobile connection strength LEDs, 4 x ETH status LEDs, 1 x Power
- Operating temperature: -40 °C to 75 °C
- Housing: Aluminium housing, plastic panels
- Dimensions (W x H x D): 109.5 x 50 x 100 mm
- Weight: 295g
Software
- Operating system: RutOS (OpenWrt based Linux OS)
- Mobile features: Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
- Network features: Routing, Failover, Firewall, DHCP, DDNS, QoS / SQM, Load Balancing, VoIP passthrough, Connection monitoring, SSHFS
- Monitoring and Management: WEB UI, CLI, SSH, CALL, SMS, TR-069, SNMP, JSON-RPC, MQTT, BACnet, DNP3, OPC UA, MODBUS, RMS
- VPN and tunneling: OpenVPN, IPsec, GRE, PPTP, L2TP, L2TPv3, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc
- Cloud solutions: RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
- Wireless Connectivity Features: Fast roaming (802.11r), Relayd
- Hotspot: External/Internal Radius, SMS OTP, MAC authentication, Walled Garden
- GNSS: NMEA forwarding, NTRIP, AVL, Geofencing
