Flexxon ECON II eMMC 64GB Commercial Grade 153ball - FEMC064G-M11
Flexxon’s ECON II eMMC is fully compliant with JEDEC eMMC 5.1 Standard. It is a combination of an embedded flash controller and 3D NAND flash memory in one JEDEC standard package, 153ball (11.5mm x 13mm). Flexxon eMMC provides high performance, good reliability and advanced power management. It is suitable for small, low power electronic devices.
£22.83
Additional information
Expected delivery time
Not all of our products are held in our local warehouse. After placing an order we will contact you with a proposed delivery date. If you would like to know the status before placing an order, please contact us.
Volume Orders
Please contact us to discuss higher volume order requirements
Available Offer
Product Details
Flexxon ECON II eMMC 5.1 includes the following features:
Compliant with eMMC Specification Ver. 5.1
Backward compatible to eMMC Specification version 4.5 to 5.0
Package of eMMC - 11.5 mm x 13 mm x 1.0mm
Temperature Range - Operation:-25°C ~ 85°C, Storage:-40°C ~ 85°C
Operating Voltage - VCC: 3.3V, VCCQ:1.8V/3.3V
Bus Mode - High-speed eMMC protocol, Clock frequency: 0 ~200MHz
Supports three data bus widths: 1 bit (default), 4 bits, 8 bits
Supports High Speed Mode HS400
Supports Production State Awareness
Supports Field Firmware Update
Supports Power Off Notification
Support Enhanced Data Strobe
Support Secure Write Protection
RoHS compliant
